Product Description


ConfigurationIn-line, 6-cylinder, 4-stroke diesel
AspirationTurbocharged / Aftercooled
Displacement14.9 L (912 in3)
Bore & Stroke137 X 169 mm (5.39 X 6.65 in)
RotationCounterclockwise facing flywheel
Fuel SystemCummins XPI Fuel System
Advertised Horsepower450-600hp (336-447 kW)
Peak Torque1650-2050 lb-ft (2237-2779 Nm)
Governed Speed1800 rpm
X15 Propulsion Engines (Variable Speed Ratings)Horsepower (kW)Speed (RPM)Rated SpeedGal/hr (Lhr)ISO*Gal/hr (L/hr)Emissions
X15-M450 (336)180024.0 (90.9)61.3 (24.0)IMO2, EPA3
X15-M450 (336)180021.7 (82.3)57.6 (15.2)IMO2
X15-M500 (373)180025.8 (97.8)57.6 (15.2)IMO2, EPA3
X15-M500 (373)180024.0 (90.9)67.2 (17.8)IMO2, EPA3
X15-M575 (429)180024.0 (90.9)63.1 (16.7)IMO2, EPA3
X15-M600 (447)180028.8 (109.1)78.1 (20.6)IMO2, EPA3



X15 Auxiliary Engines (Variable Speed Ratings)Horsepower (kW)Speed (RPM)Rated SpeedGal/hr (Lhr)ISO*Gal/hr (L/hr)Emissions
X15-DM500 (373)1500 (50 Hz)23.3 (88.4)45.2 (11.9)IMO2
X15-DM500 (373)1500 (50 Hz)24.5 (92.8)50.1 (13.2)IMO2
X15-DM500 (373)1800 (60 Hz)25.4 (96.0)48.1 (12.7)IMO2, EPA3
X15-DM570 (425)1800 (60 Hz)27.4 (103.9)52.7 (13.9)IMO2

Engine Design – Robust engine block designed for continuous duty operation and long life. Single cylinder head with four valves per cylinder enhances performance. Base engine design has been in the market for over 15 years.

Fuel System – Cummins XPI Fuel System, High Pressure Common Rail

Lubrication System – Cast aluminum oil pan designed to resist corrosion, spin-on Fleetguard oil filters

Cooling System – Front mount and low profile Heat exchanger or Keel cool with one loop system and high flow pump

Air Intake System – Cummins Turbo Technologies HX60 turbocharger optimized for marine applications

Exhaust System – Dry exhaust manifold to deliver improved fuel economy

Electrical System – 24v system with marine grade wiring harness and instrument panels

Electronics – Cummins Engine Control Module CM2350 provides engine protection through de-rates and automated engine shutdown to prevent catastrophic failures. CM2350 also provides fuel sensor monitoring, gear pressure and temperature as well as digital engine start/stop functionality. Available 24V system and standard marine grade wiring harness.

Certifications – Complies with U.S. EPA Tier 3, EU Stage 3a and IMO Tier II emissions regulations

Optional Equipment

C Command Connect available or open architecture

Flywheel housing: SAE0

Vessel System Integration: ED-4 displays—rudder position, fuel level, ONAN Gen Set information

Hydraulic Pump Drive: SAE B flanges

Front PTO available
